GoetheLab - Discovering new production technologies and supporting the university’s scientific program

3 min read
GoetheLab - Discovering new production technologies and supporting the university’s scientific program

Customer: Marco Skupin, FH Aachen – University of Applied Sciences
Country: Germany
Industry: Research, Education
Application: Prototyping, Material Study
Uses: Research in possibilities and limitations of benchtop systems
Top reasons: Low System Cost, Compact Size, Complexity, Low Operating Cost

Background

Since 2000, the teaching and research area High- Performance Manufacturing Technology and Additive Manufacturing in the Department of Mechanical  Engineering and Mechatronics at Aachen University  of Applied Sciences has been concerned with the  application and further development of generative manufacturing processes. The Goethelab has a wide range of equipment in the fields of laser powder bed fusion (LBPF), stereolithography (SLA) and fused layer modeling (FLM) which is used not only for teaching  purposes but also in numerous research projects.  The goal was to add selective laser sintering (SLS) to the portfolio in order to introduce students to another AM process and its advantages, and to be able to use  it for future research projects.

Problem

Due to its attractive low investment cost and small size, the Lisa PRO represented an excellent alternative for teaching and closer research of selective laser sintering (SLS). The lower acquisition costs of such benchtop systems result in part from smaller construction  volumes, the use of diode lasers instead of CO2-lasers, and the use of alternative beam delivery systems. Whether and to what extent these systems can keep up with industrial systems in terms of component quality has hardly been studied so far, so this was investigated in more detail as part of Marco Skupin master’s thesis.

Solution

Equipment used: Lisa PRO 3D Printer, Sandblaster, Powder Sieve
Material used: PA12, PA11 Onyx, Flexa Grey

For the study, the Lisa PRO was compared with an industrial system in terms of geometric accuracy, mechanical properties, surface  quality and economy.

In the area of geometric accuracy, for example, it was shown that the Lisa PRO achieves comparable results  to the industrial systems with ± 0.3 mm. Only in the area of component design do the design guidelines for SLS have to be given special consideration on the benchtop system due to the lower scanning speeds, otherwise greater geometric deviations will occur caused of the stronger „curling effect” on the benchtop system. Due  to the significantly lower investment costs compared  to industrial systems, there is greater cost-effectiveness in the production of very small quantities. Added to this is the plug & play system, which makes it easier to get started with selective laser sintering in training. Thus,  the Lisa PRO has proven to be the ideal system for Goethelab, acting between teaching and research.

In the area of teaching for example, students are  currently working independently on developing a concept that accompanies interaction with the Lisa PRO via an app. In the future, students should be able to teach themselves the SLS process independently  and in a practical manner with the help of digital  learning content.
With regard to research, Goethelab is currently working with their partners to investigate the laser polishability  of SLS-printed parts. In the future, this should result  in a flexible, automatable post-processing process  for the improvement of the surface.
