CreatBot

Large-scale &High performance

CreatBot

Industrial 3D printing system for Engineering-grade materials and high-performance polymers.

Small batch customization for high strength large-size prototype, design, products

New D600-PRO2 HS

£17,998.80

Quantity:

Powerful core

32-bit motherboard, equipped with a powerful NPU core processor, can quickly respond to any program instructions without delay.

Auto-rising Dual Extruders 420 ℃

D600 Pro2 HS is embedded with new smart auto-rising dual-extruder kit with hotend temperature up to 420 ℃, it adopts a new hotend with a flow rate of up to a record-breaking 90 mm³/s. The hotend can be replaced to different size one fastly. it is able to print not only huge prototypes made of ABS, ASA with fastest speed, but also PET-CF, UltraPA-CF and more high performance material with quick remove support materials for direct application. The dual-hotend is easy to maintain and affordable to replace.

Magnetic suction platform

Exclusive R&D of magnetic platform with large size, easy removable platform, high temperature resistance exceeding 100 °C, long-term use without demagnetization. For oversized models, it is easy to detach them quickly and the bottom of the model is flat. Convenient to all operators.

Camera Control Technology

Camera control technology allow customers to control printing process on speed, pause, temp., etc., with an APP remotely, achieving the best printing quality with shortest time without failure. A very useful feature on large model and long time printing.

7-inch touch screen

A new UI design language, better user interaction experience, and more convenient operation.

Z magic box: Perfect Z surface

For tall Z distance 3D printing devices, the texture of the Z-axis surface texture will deteriorate as the model height increases. Our Z-axis magic box technology can greatly reduce or even eliminate the Z-surface texture of tall models, ensuring that the surface quality of the model remains smooth and consistent.

Creatbot

Creatbot D1000 HS

£31,498.99

Quantity:

Auto-rising Dual Extruders 420 ℃

D1000 HS is embedded with new smart auto-rising dual-extruder kit with hotend temperature up to 420 ℃, it adopts a new hotend with a flow rate of up to a record-breaking 90 mm³/s. The hotend can be replaced to different size one fastly. it is able to print not only huge prototypes made of ABS, ASA with fastest speed, but also PET-CF, UltraPA-CF and more high performance material with quick remove support materials for direct application. The dual-hotend is easy to maintain and affordable to replace.

Stability

The whole-steel body not only ensure the stability during printing but also greatly extend working life. The optimization and cooperation of overall structure ensure the sustainable and efficient operation. The first batch of CreatBot 3d printers with whole-steel body have been working for 9 years and more than 30,000 hours.

Affordable And Reliable Large 3D printer

CreatBot D1000 HS was created to make industrial 3d printing of large-scale objects and prototype as easy as possible. It is an industrial 3d printer that responds to market demand and is embedded with a new smart dual extruder kit, an enclosed heated chamber, automatic leveling system and camera control for big, impressive, prints. Camera control technology allow customers to control printing process with an APP, which can get best printing quality with shortest time without failure. With a fast-heating platform and hot chamber this high-resolution large-print workhorse produces incredible results with high-quality materials. CreatBot D1000 sets a new standard in additive manufacturing and extends the material capabilities of large-scale 3d printers, it brings the possible to greatly reduce cost and time for more companies.

CreatBot D1000 HS will be your best choice with no doubt, if you are looking for an industrial large scale 3d printer for prototype and engineering-grade materials.

The most important, AFFORDABLE for every company!

Creatbot

New Creatbot PEEK 250 (250250300 )

£9,600.00

Quantity:

The World's First desktop high-temperature 3D printer with a max hot chamber of 200°C

When hot chamber reach to 180°C the outer surface temperature less than(after 5 hours heating) 40 °C

Raise the hot chamber temp. to 180°C in 20 minutes

Ultra-high temperature extruder system

Equipped with a double-tooth silicon carbide extruder, it has the characteristics of large torque, super wear resistance, and no step loss. It can print all filaments below 500°C, especially carbon fiber and glass fiber materials.

Water cooling device is necessary, which is the key to smooth printing of high-temperature filament. Hot-end is an Integrated die-casting wear-resistant nozzle, which can be replaced within 30 seconds without removing other parts or screws.

Chamber thermal insulation/safety

For the first time, an aviation-grade heat-insulating sports protective cover is used in professional-grade equipment. Through clever design, multi-path heat dissipation, customized high-temperature resistant parts, and the use of multi-layer heat-insulating materials, when the chamber temperature reaches 180°C, the temperature of the front door, top door, screen area, body, and side panel area of the machine is within 40°C, ensuring the safety of users.

One-stop annealing function

After the model is printed, there is no need to peel the model from the platform, cool it naturally, or anneal it in the annealing furnace.

You can select the "direct annealing after printing" function for the corresponding material such as PEEK, PEI, etc. on the screen in advance. You can also modify the built-in annealing temperature and time in the settings to achieve one-click annealing.

Creatbot

New Creatbot F430NX

£6,598.80

Quantity:

High temperature hotend 420°C

Using the latest technology of one-piece die-cast memory alloy hot end and super wear-resistant nozzle, temperature resistance up to 420°C. Compatible with PLA, ABS, ASA, PC, nylon, carbon fiber, and glass fiber materials. The nozzle aperture wear rate does not exceed 10% after printing carbon fiber materials for 2000 hours.

Independent Dual Extruders (IDEX)

This is the best solution for printing engineering-grade materials with independent support materials, ensuring the best quality of engineering-grade material printing. It also supports copy, mirror, and backup mode printing.

Big build volume

The printing size of single printing reaches 400*300*300mm, and the printing size with support materials reaches 360*300*300mm. The printing size is larger than that of most professional-grade products on the market.

Z axis reinforcement

The back side of the Z-axis is composed of a high-precision ball screw and 4 reinforced optical axes, with high-precision tight fit and synchronous movement. The surface of the model is uniform and free of impurities, improving the printing surface quality of engineering-grade materials.

Active heating of hot bed/chamber

The active heated bed heating temperature reaches 140°C and the active chamber heating temperature reaches 70°C. It effectively prevents the shrinkage and cracking of engineering-grade materials, allowing ABS, ASA, PC, Nylon, UltraPA-CF, etc. to be perfectly formed and the mechanical properties to be maximized.

Superior Dimensional Accuracy

The F430 NX is specifically designed with a tight combination of high-precision machined structures to maintain dimensional accuracy and tight tolerances when printing the largest parts in engineering-grade materials. Not only does the F430 NX avoid warping and layer adhesion issues, but it creates massive parts with industrial-grade precision.

High-resolution touch screen

Adopting 5-inch high-resolution capacitive touch screen, it has no delay in operation, delicate touch, user-friendly interface and convenient operation and management.
