Formlabs High Temp Resin (Form 4) 1 L
£204.00
Couldn't load pickup availability
High Temp Resin is among the most heat-resistant Formlabs resins, with a heat deflection temperature (HDT) of 238 °C at 0.45 MPa.
Choose High Temp Resin to print detailed, precise prototypes and end-use parts that require high thermal stability, such as moulds and inserts, parts exposed to hot air, gas, and fluid flow, as well as heat-resistant mounts, housings, and fixtures.
| Specification | Value |
|---|---|
| Print Technology | SLA |
| Minimum Layer Thickness | 25 micron |
| Categories | High Stiffness, Temperature Resistant |
| Colours | Translucent |
| Applications | Rapid Tooling, End-Use Parts, Rapid Prototyping |
| Tensile Modulus | 2800.0 MPa |
| Flexural Modulus | 2800.0 MPa |
| Ultimate Tensile Strength | 49.0 MPa |
| Flexural Strength | 97.0 MPa |
| Notched Izod | 17.0 J/m |
| Elongation at Break | 2.3% |
| Heat Deflection Temp. @ 1.8 MPa | 101.0 °C |
| Heat Deflection Temp. @ 0.45 MPa | 238.0 °C |
| Thermal Expansion | 75.0 μm/m/°C |
Compatibility
Compatible Tank: Form 4 Resin Tank, Form 2 Resin Tank (PDMS), Form 2 LT Tank, Form 3 Resin Tank V2.1, Form 3L Resin Tank V3
Compatible Build Platform: Form 4 Build Platform, Form 4 Flex Build Platform, Form 3 Build Platform, Form 3 Build Platform 2, Form 3 Stainless Steel Build Platform, Form 3L Build Platform, Form 3L Build Platform 2L, Form 4L Build Platform, Form 4L Flex Build Platform
Compatible Printer: Form 4, Form 4B, Form 4L, Form 4BL, Form 3, Form 3L, Form 3B, Form 3BL, Form 2
Why Choose High Temp Resin?
Our best material for stability under heat, High Temp Resin offers the highest heat deflection temperature among Formlabs resins.
High Thermal Stability
High Temp Resin offers the highest heat deflection temperature of any Formlabs material.
Ease of Use
Formlabs' accessible technology makes it easy to experiment with high temperature applications.
Applications
With the highest heat deflection temperature of any Formlabs material, High Temp Resin is ideal for applications that require resistance to high temperatures.
Heat-Resistant Prototypes
Create detailed, precise prototypes that need to withstand elevated temperatures.
Hot Air, Gas, and Fluid Flow
Print components exposed to hot air, gas, and fluid flow.
Moulds and Inserts
Produce high-temperature moulds and inserts for rapid tooling workflows.
Heat-Resistant Mounts, Housings, and Fixtures
Create mounts, housings, and fixtures that need thermal stability.
Material Properties
Download High Temp Resin Technical Data Sheet
| Parameter | Green | Post-Cured at 60 °C | Post-Cured for 120 min at 80 °C and 180 min at 160 °C |
|---|---|---|---|
| Ultimate Tensile Strength | 21 MPa | 58 MPa | 49 MPa |
| Tensile Modulus | 0.75 GPa | 2.8 GPa | 2.8 GPa |
| Elongation at Break | 14% | 3.3% | 2.3% |
| Flexural Modulus | 0.7 GPa | 2.6 GPa | 2.8 GPa |
| Notched Izod | 33 J/m | 18 J/m | 17 J/m |
| Heat Deflection Temp. @ 1.8 MPa | 44 °C | 78 °C | 101 °C |
| Heat Deflection Temp. @ 0.45 MPa | 49 °C | 120 °C | 238 °C |
Post-Processing
Washing
The foundational step in any SLA post-processing workflow is to remove any excess resin on the surface of the parts through an alcohol or ether wash.
Settings: Form Wash | Form Wash L
Curing
Post-curing Engineering and Specialty Resins is essential for parts to achieve their full strength and functionality. This step completes the chemical reaction initiated during printing, transforming the part from its green state into a fully finished component.
Settings: Form Cure V1 | Form Cure V2 | Form Cure L V1 | Form Cure L V2
